Suction Strainer – SC 3
The Hydroline SC 3 Suction Strainer is a heavy-duty, tank-mounted filtration component designed to protect hydraulic pumps from catastrophic failure. Placed directly inside the oil reservoir on the pump’s intake line, it acts as the primary defense system by trapping large particulate contaminants before they can enter the hydraulic circuit.
- Operating Pressure : High Performance Range
- Application : Industrial & Mobile Systems
About this item
The Hydroline SC 3 Suction Strainer is an in-line hydraulic filter manufactured by Hydroline Products. It is specifically designed to fit into the suction lines of hydraulic pumps to prevent large solid debris and foreign contaminants from entering and damaging the system.
| Full Model Name | Thread Size (BSPP) | Rated Flow Capacity | Screen Surface Area |
|---|---|---|---|
| Hydroline SC3-003 | 3/8″ | 12 LPM | 187 Sq. cm |
| Hydroline SC3-005 | 1/2″ | 20 LPM | 226 Sq. cm |
| Hydroline SC3-010 | 1″ | 40 LPM | 542 Sq. cm |
| Hydroline SC3-020 | 1-1/2″ | 80 LPM | 1161 Sq. cm |
| Hydroline SC3-030 | 1-1/2″ | 120 LPM | 1393 Sq. cm |
| Hydroline SC3-040 | 2″ | 160 LPM | Varies |
| Hydroline SC3-100 | 3″ | 400 LPM | Varies |
