PVR Series – Single
Yuken Demcon PVR Series Single Vane Pumps serve as a high-performance, fixed-displacement hydraulic power source for widespread industrial machinery. They combine a heavy-duty cast iron body with a precision rotary mechanism to deliver a reliable, constant volume of hydraulic fluid per shaft rotation.
- Operating Pressure : High Performance Range
- Application : Industrial & Mobile Systems
About this item
The Yuken PVR Series Single Vane Pumps are high-efficiency, fixed-displacement hydraulic power sources designed for industrial machinery. Manufactured with a robust cast iron structure, they provide stable delivery rates, exceptionally low noise levels, and minimal flow pulsation.
| Parameter / Feature | PVR1T Series | PVR50 Series | PVR150 Series |
|---|---|---|---|
| Geometric Displacement | 3.5 to 22.0 cm3/rev | 10.5 to 45.0 cm3/rev | 57.0 to 116.0 cm3/rev |
| Max Operating Pressure | Up to 210 kgf/cm2 | Up to 175 kgf/cm2 | Up to 175 kgf/cm2 |
| Operating Speed Range | 750 to 1800 RPM | 600 to 1800 RPM | Up to 1800 RPM |
| Core Design Feature | Low noise levels | Minimal flow pulsation | High-volume delivery |
| Maintenance Mechanism | Replaceable cartridge kit | Replaceable cartridge kit | Replaceable cartridge kit |
| Housing Material | Heavy-duty cast iron | Heavy-duty cast iron | Heavy-duty cast iron |
| Fluid Compatibility | Mineral oil / Phosphate ester | Mineral oil / Phosphate ester | Mineral oil / Phosphate ester |
| Mounting Configurations | Flange or Foot mounting | Flange or Foot mounting | Flange or Foot mounting |
